Kullanım kılavuzu Electrolux Z5505 Elektrikli süpürge

Kullanım kılavuzu

Before you start, please refer to the electrical safety instructions on

page 63 (U.K. and Ireland only).

Electrolux supply a range of cleaners with different

specifications and accessories. Please refer to your model

number whilst reading this booklet.

Keep both cover flaps open and cross reference pictures with

text where necessary.

Tools for your Vacuum Cleaner

B

Dust bags

C

Telescopic tube 5510

B

Back Saver

®

tubes 5505/15/20/22/25/28/30/33/35/36/40

D

Hose handle

E

Carpet/hard floor nozzle

Turbo nozzle 5540

G

Crevice nozzle

H

Upholstery nozzle

I

Dusting brush

K

Tool holder

Ensuring your safety

The cleaner is for domestic use only and has been designed to

ensure maximum safety and performance. Please follow these

simple precautions:

L

The cleaner is double-insulated so it must not be earthed

M

The cleaner is only to be used by adults. Young or infirm

persons should be supervised to ensure they do not play with

the appliance

N

Always store in a dry place

O

Do not use to pick up liquids

P

Avoid sharp objects

Q

Do not pick up hot cinders or lighted cigarette ends

R

Do not use near flammable gases

S

Avoid tugging on the mains cable and check cable regularly

for damage

T

Note: Do not use cleaner with a damaged cable. If damaged

the cable should be replaced at an Electrolux Service Centre

U

The plug must be removed from the socket-outlet before

cleaning or maintaining the appliance

W

All service and repairs must be carried out by authorised

Electrolux service staff

Getting started

1

Check the dust bag is in place.

2

Insert hose until catch clicks to engage (press catch to

release).

3

Attach telescopic tube 5510 to hose handle.

4

Attach telescopic tube 5510 to floor nozzle (to disconnect

twist and pull apart).

5

Extend the cable and connect to mains. The cleaner is fitted

with cable rewind. Press foot pedal to rewind (please hold the

plug to prevent it striking you).

6

Move switch forward 5510/15/20/22/25/28/30/33/35/36/40

to reel cable in/out as required, and back to lock extended

cable in place.

7

Press on/off foot pedal to activate cleaner.

8

To increase/decrease suction, adjust control on cleaner body.

9

Suction can also be regulated on hose handle by

opening/closing aperture.

Using the Back Saver

®

tubes

The Back Saver

®

tubes have been designed for use in different

positions: General Cleaning & Cleaning Under Low Furniture.

10

Before you start please note the position of the tubes and

catches as indicated

*

in the diagrams.

Attach the larger tube

A to the hose handle and the smaller

tube

B to the floor nozzle until the catches click to engage.

Attach tubes

A+B together until the catch clicks to engage.

11

Use the tubes in this position for general cleaning.

12

To change position, push the catch on the smaller tube B and

turn smaller tube

B through a half circle until the catch clicks

to engage.

12a

Now simply turn the rotary head of the nozzle through a half

circle.

13

Use the tubes in this position for cleaning under low furniture.

13a

This position can also be used for cleaning hard to reach

places such as on top of wardrobes and bookshelves.

Your Vacuum Cleaner features

A

X

Mains cable

B

Y

Cable foot pedal

C

z

Suction control regulator

D

0

Dust bag full indicator 5505/10/15/20/22/25/28

E

1

HEPA filter indicator 5530/33/35/36/40

F

2

Overheat Indicator: Indicator will ‘flash’ if cleaner overheats

5530/33/35/36/40

G

3

Dust bag full indicator 5530/33/35/36/40

H

l

Cover release for dust bag/filter compartment

I

m

Hose connection

J

4

Power outlet (for the use of power driven tools)

5530/33/35/36/40

K

g

Back Saver

®

carrying handle

L

K

Tool holder (for attachment to hose handle)

M

i

On/off switch

N

5

Temporary parking position for floor nozzle and tubes when

in use

O

k

Storage slot for floor nozzle and tubes when not in use

Getting the best results

Using Carpet/Hard floor nozzle

v

Carpets: Use floor nozzle with lever in this position.

Reduce suction power for loose rugs.

u

Hard floors: Use floor nozzle with lever in this position.

5505 • 5510 • 5515 • 5520 • 5522 • 5525

5528 • 5530 • 5533 • 5535 • 5536 • 5540

English

F
