5

ENGLISH

USING THE CHRONOGRAPH

This chronograph is able to measure and display time in 1/2 second up to

maximum of 11 hours 59 minutes 59 seconds. The chronograph second hand

keeps continuously for 11 hours 59 minutes 59 seconds after starting.

MEASURING TIME WITH THE CHRONOGRAPH

1. The chronograph can be started and stopped each time pusher “A”

is pressed.

2. Pressing pusher “B” resets the chronograph and the chronograph second

hand, chronograph minute hand, and chronograph hour hand return to

zero position.

TIME MEASUREMENT

STOP

RESET

CHRONOGRAPH RESET (INCL. AFTER REPLACING BATTERY)

This procedure should be performed when the chronograph second hand does

not return to zero position after the chronograph has been reset, including after

the battery has been replaced.

1. Pull the crown out to the 2nd position “C”.

2. Press pusher “A” to set the chronograph second hand to the zero position.

The chronograph hand can be advanced rapidly by continuously pressing

pusher “A”.

3. Once the hand returns to zero position, return the crown to the normal

position.

*Do not push crown to normal position while the chronograph second hand

returns to zero position.It stops on the way when crown is returned to normal

position and its position is recognized as zero position.

TYPE 3

B

D

A

C

PUSHER “A”

DATE

CHRONOGRAPH

1/20 SECOND

CROWN

POSITION

PUSHER “B”

SECOND

CHRONOGRAPH

SECOND

CHRONOGRAPH

MINUTE

HOUR

MINUTE



NORMAL POSITION

BASIC OPERATIONS

• 6 o’clock eye shows seconds.

• 10 o’clock eye shows “minutes elapsed” for chronograph.

• 2 o’clock eye shows “1/20 seconds elapsed” for chronograph.

• Chronograph second hand shows “seconds elapsed” for chronograph.

TIME

TO SET THE TIME:

1. PULL crown out to “C” position.

2. TURN crown either way to correct time.

3. PUSH crown in to “A” position.

TO ADJUST TO A NEW TIME ZONE:

1. PULL crown out to “B” position.

2. TURN crown either way to move the hour hand in hour increments.

CALENDAR

TO SET THE CALENDAR:

1. PULL crown out to “B” position.

2. TURN crown either way to move hour hand. Two complete revolutions

relative to the 12 o’clock position will move the date forward or backward.

This will correct both date and 24-hour time.

3. PUSH crown in to “A” position.

NOTE: The date changes automatically every 24 hours.

CHRONOGRAPH

THE CHRONOGRAPH IS CAPABLE OF MEASURING:

• 1/20 seconds elapsed up to 1 second (2 o’clock eye).

• Seconds elapsed up to 1 minute (chronograph second hand).

• Minutes elapsed up to 30 minutes (10 o’clock eye).

NOTE: Chronograph will operate continuously for 4 hours, after which it will

automatically stop and reset.

NOTE: The 1/20th of a second hand does not move during chronograph

function, the 1/20th seconds are indicated when chronograph is stopped and

not yet reset.

BEFORE USING THE CHRONOGRAPH, adjust all the chronograph hands to

the “0” or 12-hour positions.

TO ADJUST CHRONOGRAPH HANDS:

1. PULL crown out to “B” position.

2. PRESS pusher “B” until the hand at the 10 o’clock eye resets to the “30”

position.

3. PULL crown out to “C” position.

4. PRESS pusher “A” until the chronograph second hand resets to the “0” or

“60” or 12-hour position.

5. PRESS pusher “B” until the hand at the 2 o’clock eye resets to the “0”

position.

6. PUSH in Crown to “A” position.

NOTE:

• Make sure the chronograph is stopped and reset before adjusting.

• PRESSING and HOLDING either pusher “A” or “B” for 2 seconds will cause

the hands to move continuously until the pusher is released.

STANDARD CHRONOGRAPH MEASUREMENT:

1. PRESS pusher “A” to start timing.

2. PRESS pusher “A” to stop timing.

3. PRESS pusher “B” to reset.

SPLIT TIME MEASUREMENT:

1. PRESS pusher “A” to start timing.

2. PRESS pusher “B” to split.

3. PRESS pusher “B” to resume timing.

4. PRESS pusher “A” to stop timing.

5. PRESS pusher “B” to reset.

INDIGLO

®

NIGHT-LIGHT

With the crown in the “A” position, PUSH crown to the “D” position. Entire dial

will be illuminated. Electroluminescent technology used in INDIGLO

®

night-light

illuminates entire watch face at night and in low light conditions.

NIGHT-MODE

®

FEATURE:

1. PUSH and HOLD Crown to “D” position for 4 seconds to activate NIGHT-

MODE

®

feature. PRESSING any pusher will cause the INDIGLO

®

night-light

to stay on for 3 seconds.

2. NIGHT-MODE

®

feature will stay activated for 8 hours.

3. Or PUSH and HOLD Crown to “D” position for 4 seconds to deactivate.

IF STOPWATCH HANDS DO NOT RETURN TO “0 POSITION” WHEN THE

STOPWATCH IS RESET:

1. PULL crown out to “B” position

2. PRESS pushers “A” or “B” repeatedly to move hands to “0” position

3. PUSH in crown to “A” position
