6

ENGLISH

TYPE 4

A

B

BASIC OPERATIONS

• 6 o’clock eye displays “seconds elapsed” for the chronograph

• 9 o’clock eye displays “minutes elapsed” for the chronograph

• 3 o’clock eye displays the current time in a 24 hour format

TIME

TO SET THE TIME:

NOTE: The stopwatch must be stopped and reset to the zero position prior to

setting the time.

1. Pull the crown out to position B.

2. Rotate the crown either direction until the 24-hour, hour, and minute hands

display the correct time.

3. Push Crown in to position A.

TO ADJUST THE STOPWATCH HANDS TO THE ZERO POSITION:

1. Pull the crown out to position B.

2. Press pusher “A” to move the stopwatch minute and second hands counter

clockwise to the zero position. Press pusher “B” to move the stopwatch

minute and second hands clockwise to the zero position.

3. Push Crown in to position A.

CHRONOGRAPH

THE CHRONOGRAPH IS CAPABLE OF MEASURING:

• Seconds elapsed up to one minute (6 o’clock eye)

• Minutes elapsed up to one hour (9 o’clock eye)

STANDARD CHRONOGRAPH MEASUREMENT

• Press pusher “A” to start timing

• Press pusher “A” to stop timing

• Press pusher “B” to reset the chronograph to the zero position

SPLIT TIME MEASUREMENT

• Press pusher “A” to start timing

• Press pusher “B” to split

• Press pusher “B” to resume timing

• Press pusher “A” to stop timing

• Press pusher “B” to reset the chronograph to the zero position

TYPE 5

B

C

7

SETTING THE TIME

1. PULL the crown out to the 2nd position “C”.

2. Turn the crown to set hour and minute hands. Make sure that the 24-hour

time is correct.

3. When the crown is pushed back to the normal position “A”, second hand

begins to run.

SETTING THE DATE

1. PULL the crown out to the 1st position “B”.

2. Turn the crown counter-clockwise to set the date. *If the date is set between

the hours of around 9:00 PM and 1:00 AM, the date may not change on the

following day.

3. After the date has been set, push the crown back to the normal position “A”.

USING THE CHRONOGRAPH

This chronograph is able to measure and display time in 1-second increments

up to maximum of 29 minutes 59 seconds. The chronograph second hand

moves continuously for 30 minutes after starting.

STANDARD CHRONOGRAPH MEASUREMENT:

1. PRESS pusher “A” to start timing.

2. PRESS pusher “A” to stop timing.

3. PRESS pusher “B” to reset.

SPLIT TIME MEASUREMENT:

1. PRESS pusher “A” to start timing.

2. PRESS pusher “B” to split.

3. PRESS pusher “B” to resume timing.

4. PRESS pusher “A” to stop timing.

5. PRESS pusher “B” to reset.

CHRONOGRAPH RESET (INCL. AFTER REPLACING BATTERY)

This procedure should be performed when the chronograph minute hand or

second hand do not return to zero position after the chronograph has been

reset, including after the battery has been replaced.

1. Pull the crown out to the 2nd position “C”.

2. Press pusher “A” or “B” to set the stopwatch hands to the zero position.

The movements of the stopwatch minute hand and the stopwatch second

hand are interlocked. To set the stopwatch minute hand to the zero position,

continue to move the stopwatch second hand until the stopwatch minute

hand reaches the zero position.

3. Once the hands returns to zero position, return the crown to the normal

position.

TYPE 6

B

C

7

SETTING THE “HOME” TIME (WILL BE DISPLAYED ON THE 24-HOUR

SUB-DIAL AT THE 12 POSITION AND THE 4TH CENTER HAND)

1. Wait until the second hand is pointing to 60.

2. PULL the crown out to the 2nd position “C”.

3. Turn the crown to set the 4th center Hour hand and the hour hand in the

24-hour sub-dial to the correct position to display your “HOME” time

(the time at your home location).

NOTE: If you are in an area of the world that does not follow the standard

minutes within the hour, set the minute hand to the correct time of the your

local location.

SETTING THE “LOCAL” TIME (WILL BE DISPLAYED ON THE STANDARD

HOUR AND MINUTE HANDS)

4. PUSH the crown in to the 1st position “B”.

5. Turn the crown COUNTER-CLOCKWISE to set the STANDARD Hour hand to

the correct position to display the “local” time (the time at the location you are

currently located).

6. PUSH the crown in to the normal position “A”. The second hand in the

sub-dial at the 6 position will begin to move.

HOUR HAND

SECOND HAND

STOPWATCH

MINUTE HAND

STOPWATCH

SECOND HAND

PUSHER “A”

MINUTE HAND

CROWN POSITION

NORMAL POSITION “1”

PUSHER “B”

24-HOUR HAND

PUSHER “A”

MINUTE HAND

CROWN POSITION

NORMAL POSITION “A”

PUSHER “B”

SECOND HAND

DATE

24-HOUR TIME

CHRONOGRAPH

MINUTES

CHRONOGRAPH

SECONDS

HOUR

24-HOUR TIME

CHRONOGRAPH

MINUTES

HOUR

SECONDS

CHRONOGRAPH

SECONDS

PUSHER “A”

MINUTE HAND

CROWN POSITION

NORMAL POSITION “A”

PUSHER “B”

DATE

2nd HOUR HAND
